31X10W LED CAR SHOW LIGHT

Model PL-EL-31C
Device Type  LED CAR SHOW LIGHT
SKU: PL-EL-31C Category: Tags: ,

Overview

The PL-EL-31C 31×10W LED Car Show Light is a high-performance fixture specially designed for car shows, exhibitions, and display lighting applications. Featuring 31pcs high-power 10W CREE white LEDs, it provides bright, stable, and flicker-free illumination with a long lifespan. With multiple beam angle options, DMX control, and versatile mounting capability, this fixture is perfect for creating stunning visual effects in automotive displays and professional events.


Key Features

  • Powerful Illumination: Equipped with 31×10W CREE white LEDs for brilliant and uniform lighting.

  • Long-Lasting Performance: LED lifetime rated up to 50,000 hours.

  • Flexible Beam Angles: Standard 25° beam angle, with optional 30° or 45° lenses for different applications.

  • Smooth & Flicker-Free Dimming: 0–100% linear dimming for precise control.

  • Strobe Effect: Adjustable strobe up to 20 F.P.S.

  • User-Friendly Operation: Digital display and end-to-end connection capability.

  • Control Options: Supports DMX512, automatic mode, and master/slave mode.

  • Compact & Robust Design: Lightweight construction with IP20 rating for indoor use.

Item Specification
Light Source 31 × 10W CREE White LEDs
LED Lifetime 50,000 hours
Color Temperature 5600K
CRI Ra ≤ 70
Beam Angle 14.7°
Effects 0–100% linear dimmer, electronic strobe 0.3–20 fps
Barn Door 4 rotating barn doors
Control Protocol DMX512 / 1990 standard
DMX Channels 2
Display Digital display
Working Environment Indoor
IP Rating IP20
Power Supply AC 100–240V, 50/60 Hz
Max Power Consumption 330W
Connections PowerCon In/Out, 3-pin & 5-pin DMX in/out (locking XLR)
Dimensions (W × D × H) 515 × 270 × 275 mm (20.28 × 10.63 × 10.83 in)
Weight 8.3 kg (18.30 lbs)

PL-EL-31C
