380 BEAM LIGHT

Model PL-M-380B
Device Type BEAM LIGHT
SKU: PL-M-380B Category: Tags: , Brand:

The PL-M-380B is a professional 380W beam moving head light designed for high-impact stage and event applications. Featuring a powerful 380W lamp, sharp optics, and a wide range of dynamic effects, it delivers intense beams, vivid colors, and creative patterns. With precision pan/tilt movement, electronic focus, and advanced prism options, this fixture is ideal for concerts, clubs, theaters, and large-scale outdoor events.


Key Features

  • High-Output Light Source: 380W lamp with 7500K color temperature

  • Optical Effects: 14 fixed colors + open with rainbow effect, 11 static gobos + 3 glass gobos

  • Dynamic Visuals: 8-facet and 16-facet rotating prism, strobe with variable speed, excellent color macro effects

  • Precision Control: Pan 540° / Tilt 250° with 16-bit resolution

  • User Interface: LCD display with intuitive menu navigation

  • Control Modes: DMX512, automatic, and master/slave operation

  • Connectivity: 3-pin and 5-pin DMX in/out

  • Versatile Applications: Perfect for concerts, festivals, clubs, and stage productions

Item Specification
Light Source 1 × 380W Osram Blast Lamp
Lamp Lifetime 1500 hours
Color Temperature 7500K
Color Wheel 8 fixed colors + open
Static Gobo Wheel 14 gobos + open
Rotating Gobo Wheel 7 gobos + open
Prisms 8-facet & 16-facet rotating prisms
Dimmer 1–100% linear dimming
Strobe Electronic, 0–25 fps
Control Protocol DMX512, RDM
DMX Channels 19
Control Modes Auto, Master/Slave, DMX, Sound activation, RDM
Pan/Tilt Resolution 16-bit
IP Rating IP20
Power Supply AC 100–240V auto-sensing, 50/60 Hz
Max Power Consumption 550W
Connections PowerCon In/Out, 3-pin & 5-pin DMX in/out (locking XLR)
Dimensions (W × D × H) 293 × 395 × 700 mm (11.54 × 15.55 × 27.56 in)
Weight 20.8 kg (45.86 lbs)

PL-M-380B
